Rubber and plastic balls

Rubber and plastic balls - Durable and versatile

Rubber and plastic balls are mainly used as seals in valves and pumps or for cleaning pipelines, heating systems and screening systems. Depending on the requirements, we use different types of rubber for our rubber balls in order to be able to offer the right material properties for every application. For this reason, our valve balls and strainer cleaning balls can be found in many areas of the chemical industry as well as in mechanical and plant engineering. Our rubber and plastic balls are characterized by their high durability and resistance.

Quickfacts Rubber and plastic balls

Application

Valve balls, sieve knocking balls, cleaning balls

Materials

NR, SBR, EPDM, CR, NBR, SI, FPM/FKM

Core materials

e.g. wood, cork, steel, cast iron, aluminum, hollow steel cores

Hardness

35 ± 5 Shore A to 85 ± 5 Shore A

Colors

on request

Quantity

as of 1

Manufacture

CM, TM, IM

Dimensions

Ø 3.2 – 300 mm (others on request)

Application	Valve balls, sieve knocking balls, cleaning balls
Materials	NR, SBR, EPDM, CR, NBR, SI, FPM/FKM
Core materials	e.g. wood, cork, steel, cast iron, aluminum, hollow steel cores
Hardness	35 ± 5 Shore A to 85 ± 5 Shore A
Colors	on request
Quantity	as of 1
Manufacture	CM, TM, IM
Dimensions	Ø 3.2 - 300 mm (others on request)

Discover our range of products now!

You will find a wide range of high-quality products here – the right solution for every challenge.

Request a free sample now

Get your desired product sample free of charge by filling out our request form. Our team is happy to help!

Request sample

Free sample

Rechter Bereich

Form of address

E-Mail *

First name *

Nachname *

Company *

ZIP CODE *

City

Straße, Nr.

Sample selection

Your message

Checkboxen *

Hiermit akzeptiere ich die Datenschutzbestimmungen.

* = Pflichtfeld

Captcha

If you are human, leave this field blank.

Application areas

Rubber valve balls

In valves, rubber balls act as a common shut-off device, preventing the unwanted backflow of gases, liquids or granular substances and dusts. The freely movable rubber ball is located in the cage of the ball valve and is lifted out of the valve seat by the inflowing medium.

In the event of backflow, the ball is pressed back into the hard valve seat by force and its own weight, thereby creating a seal. The valve seat should be adapted to the material used for the valve ball.

Another field of application is the area of float balls. Ball concepts with buoyant elastomers and core materials are used here. We have suitable elastomer and plastic materials available for the various specific operating conditions.

Screen cleaning balls made of rubber with high rebound resilience

Our rubber balls are used for cleaning industrial screening systems. The balls are added to the material to be screened and, due to their bouncing behavior, ensure permanently recurring collisions with other balls, with the material to be screened and with the screen itself. These recurring impulses keep the screen passages clear.

In order to counteract the resulting abrasion pressure and ensure the required bounce behavior, we use materials that are characterized by low abrasion and good rebound elasticity. This achieves the best possible results during the cleaning process.

Our expertise in the field of rubber screen cleaning balls enables us to produce a wide range of standard sizes as well as numerous intermediate sizes in various degrees of hardness to suit your specific sealing application.

Our services & product features

We offer a wide range of different versions of our rubber balls for customer-specific applications: We can manufacture the rubber balls not only in solid design, but also with different cores made of cork, wood, aluminum, steel, lead, cast iron, hollow steel core (also with sand filling).

Cores

In addition to the material, the ball weight is also decisive for the proper functioning of the ball valve. This is determined by the material itself or by the use of different cores in the ball body. We mainly use solid and hollow cores made from the following materials:

Ball with lead

Ball with cork

Ball with wood

Ball with aluminum

Ball with steel

Ball with casting
